Phase angle measurement requires that two signals with identical periods be applied to Channels A and B. A display from -180º to +180º is obtained by timing the rising edge of one channel and the falling edge of the other channel, and programming a 180º offset. A resolution of 1º, 0.1º or 0.01º is selectable. Accuracy is 0.01% up to 100 Hz, 0.1% at 1 kHz, and 1% at 10 kHz.
